Description
Can mix load all RF 2.4G Wireless Series products, including LED controllers, LED dimmable drivers,
LED lights, 0-10V and Triac dimmers.
Can control dimming, color temperature, RGB, RGBW and RGB+CCT light effects.
Can be set on 1-16 zones, and 8 scene memories.
Includes one micro USB cable.
Available on Android and IOS software (App Name: SkySmart)
TECHNICAL DETAILS
Operating Voltage & Current: DC5-24V,300mA
Wireless standard: 802.11 b/g/n
Frequency range: 2.412GHz~2.484GHz
Remote Distance: 30m
Working Temperature: -30℃~55℃
Product Size: Φ72×25mm
Interface Specifications:
Software Installation:
1. Download the application from Apple Store or Google Play by searching “SkySmart”.
2. If the WiFi-Relay controller is connected to your home router, then connect your smart phone to your home network.
If the WiFi-Relay controller cannot connect with your home router, then connect your smart phone to the WiFi-Relay
controller network directly.
3. Open the SkySmart application and operate according to the following instructions.
Network Connection:
