Description
This 0-10 volt DC low-voltage dimmer is designed for high-power LEDs, and other compatible drivers or light engines with a 0-10V current-sinking control. Features logarithmic response and reverse polarity protection. Product comes complete with knob, wall trim plate, mounting screws, and wire nuts.
TECHNICAL DETAILS
Connection Type: Pigtail
Output Voltage DC: 0 ~ 10 VDC
Special Features: Knob Control
Standards And Certifications: RoHS Compliant
Input voltage: AC85-265V
RF Control distance: 30M
Output current: Max 1.5A (AC)
Features:
Rotary panel 0-10V dimmer, 1 channel output.
Output 1 channel 0-10V signal, connect with 0/1-10V dimmable driver.
High voltage AC input, High voltage AC relay output.
Rotate knob to change brightness, support push and long push operation.
Compatibility with 2.4G dimming remote control.
Mechanical Structures and Installations:
Wiring diagram
:
